SERIES FEATURES

ELARGO – Beauty and the Beat

  • □
    drop-shaped, acoustically advantageous enclosure
  • □
    GAUDER Akustik XPulse drivers
  • □
    Midrange driver in closed enclosure
  • □
    Beryllium tweeter, upgradeable to diamond tweeter
  • □
    Symmetrical, ultra-steep crossover
  • □
    Integrated TDC Time Delay Control
  • □
    Steep filters > 50 dB/octave
  • □
    exclusively components from Mundorf, IT and WBT
  • □
  • Bass Extension System
  • □
    adjustable bass volume in three stages
    (-1.5 dB, linear, +1.5 dB)
  • □
    WBT BiWiring binding posts
  • □
    Clearwater internal wiring
  • □
    large, easily adjustable stand
  • □
    Front-grille with magnetic holder optionally available
Elargo 100
 		Elargo 200
 Elargo Center
Construction 3-way bass-reflex speaker, floorstanding speaker
3-way bass reflex speaker,
floorstanding speaker
2½-way center speaker
Impedance [Ohm] 4 4 4
Power handling [W] 280 480 230
Height [cm] 119 126 24
Width [cm] 26 30 52
Depth [cm] 38 43 36
Weight [kg] 40 50 18

ELARGO 100

3-way bass-reflex speaker with two 7” XPulse special long-throw bass drivers with rear-ventilated centering spider and stiffened aluminum cone. Down-firing principle for even room excitation. XPulse midrange driver with lightweight, damped, ultra-stiff aluminum cone, powerful drive and rear-ventilated centering spider. Tweeter with ultra-light beryllium dome and iron-neodymium-boron magnet for extremely high treble resolution (perfect transient response), upgradeable to diamond.

Elargo 200

3-way bass-reflex speaker with two 22 cm XPulse special long-throw bass chassis with rear-ventilated centring spider and stiffened aluminium cone. Down-firing principle for even room excitation. XPulse midrange driver with lightweight, damped, ultra-stiff aluminum cone, powerful drive and rear-ventilated centering spider in a closed midrange cabinet. Tweeter with ultra-light beryllium dome and iron-neodymium-boron magnet for extremely high treble resolution (perfect transient response), upgradeable to diamond.

Finishes

Piano lacquer black

Piano lacquer white

Rosewood high gloss

Available in piano lacquer black, piano lacquer white and in rosewood high gloss
